Bronze suction centrifugal pump BM509104-81

Bronze suction centrifugal pump BM509104-81

Bronze suction centrifugal pump are designed for reliable marine and industrial service, featuring corrosion-resistant bronze construction and self-priming capability for consistent performance in demanding applications worldwide.

PUMP SPECIFICATIONS:
Model Number .................BM509104-81
Size ................ 8" x 6" / 200 x 150 mm
Flow, Max ............... 4,000 USgpm 920 m3/h 250 l/s
Head, Max................. 650 feet / 200 meters
Flow at BEP ............ 2,800 USgpm 640 m3/h /180 l/s
Efficiency at BEP..........76%
Solids Handling, ..........1.5"
Max ..........40 mm
Operating Speed, ..........2000 rpm/ Max
Suction Connection..........8" (200 mm)/ 150 ANSI Flanges
Delivery Connection ..........6" (150 mm) / 150 ANSI Flanges
Bearing Lubrication..........Oil STD/ Grease optional
Fasteners..........Imperial
Magnetic Pump

Additional Images:

bronze product image 2
bronze product image 3
bronze product image 4
bronze product image 5
bronze product image 6
bronze product image 7
